The crane is intended for lifting and conveying operations in the shops. Load trolley has two hoists – main and auxiliary. Auxiliary hoist can be used with electric magnet.
Specifications
| Lifting capacity, t: | |
| main hoist | 80 |
| auxiliary hoist | 20 |
| Lifting height, m: | |
| main hoist | 32 |
| auxiliary hoist | 34 |
| Lifting speed, m/min | |
| main hoist | 7,5 |
| auxiliary hoist | 12,5 |
| Traveling speed, m/min | |
| crane | 80 |
| trolley | 41,4 |
| Supply voltage of power network, V | AC 380 |
