It is used as a part of bucket-wheel stripping and mining complex for conveying the material from the bucket-wheel excavator onto face conveyor or spreader.
| Capacity, m³/h | 5250 |
| Max. allowable route inclination, deg. | |
| during operation | 3 |
| during driving from one place to another | 5 |
| Conveyor belt width, mm | 2000 |
| Average ground pressure, N/cm² | 12 |
| Type of undercarriage | caterpillar |
| Traveling speed, m/h | 480 |
| Speed of swinging (full-circle-swinging machine), rpm | 1,22 |
| Supply voltage, kV | 10 |
