It is intended for loading mined bulk onto conveyor lines /transport means positioned above the level of the excavator working position.
| Capacity, m³/h | 5250 |
| Max. allowable working platform slope, deg | |
| - during operation | 3 |
| - during traveling | 5 |
| Conveyor belt width, mm | 2000 |
| Mean ground pressure, N/cm² | 20 |
| Type of undercarriage | caterpillar |
| Traveling speed, m/h | 360 |
| Height of supporting portal location (upper supporting carriagein respect to lower supporting carriage), | 32 |
| Possible lower supporting carriage travel in respect to connecting bridge, | 12 |
| Slewing angle in connecting bridge layout in respectto supporting portal (of upper supporting carriage), deg | ±115 |
| Length of loading zone, m | 12,5 |
| Height of receiving hopper (max.), m | 10 |
| Length of unloading cantilever about an axis of swinging, m | 30-35 |
| Slewing angle of unloading cantilever, deg | ±100 |
| Height of discharging, mm | |
| - minimum | 5600 |
| - maximum | 12300 |
| Supply voltage, kV | 6 |
